N301 Series

Explosion-Proof / Flameproof LiDAR

N301 Series Explosion-Proof & Flameproof LiDAR

Explosion-Proof / Flameproof LiDAR

After rigorous testing and verification, LSLiDAR has launched the N301 series of explosion-proof and flameproof LiDARs specifically designed for complex, flammable and explosive environments. This series of LiDARs is capable of conducting a comprehensive 360° scan of the surrounding environ- ment, achieving precise 2D detection. With a detection range of up to 50m and a measurement rate of up to 20,000 points per second, the LiDARs also boast an IP67 dust and water resistance rating, ensuring stable operation in various harsh environments. Widely applicable in scenarios such as gas stations, chemical plants, liquefied gas stations, oil exploration, ground patrols, and inspection.
Explosion-Proof LiDAR N301
(Ex ib I Mb)
Flameproof LiDAR N301
(Ex d II C T6 Gb)
Wavelength 905nm Communication Interface 100M Ethernet
Laser Class CLASS 1 Output Data Distance, Angle
Channels 1 Input Voltage 9~32VDC (Typical Value 12/24VDC)
Detection Method TOF Drivers Brushless Motor
Detection Range 10 / 20 / 30 / 40 / 50m Power Consumption 4W
Distance Resolution 2 mm / 4 mm Operating Temperature -20℃ ~ 60℃
Range Precision ±3cm Anti-light 80 K Lux
Horizontal FOV 360° Vibration Test 5Hz-2000Hz,3G rms
Horizontal Resolution 0.09° / 0.18° / 0.36° Shock Test 500m/sec², lasting for 11ms
FPS 5 / 10 / 20Hz Weight ≈406g(Explosion-Proof)
Data Point Generating Rate 20,000 pts/sec Dimensions (DxH) Φ80x79.1mm(Explosion-Proof)
